AVB stage box mode for StudioLive Series III mixers
32 Microphone / Line inputs XLR / jack 6.3 mm combo sockets with 48 V phantom power
Stereo aux input RCA (L/R)
16 AUX sends
16 Mix outputs 6.3 mm jack balanced
2 XLR main outputs (L/R)
Stereo headphone output 6.3 mm jack
"Mute All" button to mute all inputs and outputs
Integrated SD card recorder (stereo) for recording the main signal and as a player
40x40 USB recording interface, 55x55 AVB recording interface
Converter: 24 Bit / 48 kHz with 115 dB dynamic range
Fat channel signal processing: Polarity, high-pass filter, gate / expander with sidechain, fully parametric 4-band EQ, compressor with sidechain, limiter, including vintage plugins for EQ and compressor
4 Master effects processors including vintage reverb plugins
Line delay in all inputs and outputs
Fully parametric 6-band EQ in all outputs, 8 graphic EQs (31-Band)
Presets plus user memory for Fat Channel, effects and graphic EQ
USB connection, Ethernet control connection, Ethercon AVB audio network connection
Control software "UC Surface" for OS X, Windows, iPad and Android tablet
Free "QMix-UC" monitoring app for iPhone, iPod Touch and Android smartphones
System requirements: Mac OS x 10.8.5 64-bit or newer, Windows 7 x64/x86 SP1, Windows 8 x64/x86, Windows x64/x86
Build: 19"/ 2 U
Dimensions: 483 x 305 x 90 mm
Weight: 5 kg
Includes "Capture" recording software, "Studio One 3 Artist" DAW software, "Studio Magic" plugin suite (for download) and Fat Channel Plugin Collection
